3 Installation
746 VA Trace Analyzer / 747 VA Stand
3-6
3.3 Installation of 747 VA Stand
If the 746 VA Trace Analyzer is connected to the power supply, neither
the 746 VA Trace Analyzer nor the 747 VA Stand may be opened or
parts removed as there is a danger of contact with live components.
Before the 746 VA Trace Analyzer or 747 VA Stand is opened to
change components or for maintenance or repair work, the mains
cable must thus always be disconnected from the mains connection
plug 13 13 of the 746 VA Trace Analyzer!
3.3.1 Electrical connection at 746 VA Trace Analyzer
The 747 VA Stand may be connected to the 746 VA Trace Analyzer
only when the latter is switched off, otherwise both instruments could
suffer electrical damage!
Maximum three 747 VA Stands can be connected to the 746 VA Trace Analyzer.
Each 747 VA Stand is connected to the 746 VA Trace Analyzer with a 6.2135.000
EBUS cable, one end of which offers the possibility to attach further EBUS cables.
The two connectors of the EBUS cable are identical, it is thus immaterial which end
is plugged into which instrument.
1 Attachment of the first 747 VA Stand
• Switch off 746 VA Trace Analyzer using the mains switch 11 11.
• Plug one end of the 6.2135.000 EBUS cable into connection 22 22 of the
746 VA Trace Analyzer and fasten to the instrument by tightening the
screws in the cable connector.
• Plug the other end of the EBUS cable into connection 34 34 of the 747 VA
Stand and fasten to the instrument by tightening the screws in the cable
connector.
• Using a screwdriver, set stand address 35 35 of the 747 VA Stand to "1"
(arrow must point to the number "1").
2 Attachment of the second 747 VA Stand
• Switch off 746 VA Trace Analyzer using the mains switch 11 11.
• Plug one end of the second 6.2135.000 EBUS cable into connector of the
first EBUS cable and fasten together by tightening the screws in the cable
connector.
• Plug the other end of the second EBUS cable into connection 34 34 of the
second 747 VA Stand and fasten to the instrument by tightening the
screws in the cable connector.
• Using a screwdriver, set stand address 35 35 of the second 747 VA Stand to
"2" (arrow must point to the number "2").
