3.3 Installation of 747 VA Stand
746 VA Trace Analyzer / 747 VA Stand
3-9
40 40 Measuring head arm
41 41 Measuring head
72 72 Opening
for auxiliary electrode 60 60 (6.0343.000 Pt
auxiliary electr. or optional GC electr.
comprising 6.1241.020 Electrode holder
and 6.1247.000 GC tip)
73 73 Threaded opening
without automatic rinsing:
for dummy stopper 62 62 (6.1446.040)
with automatic rinsing:
for FEP tubing 89 89 (6.1805.180)
74 74 Threaded opening
without automatic rinsing:
for dummy stopper 61 61 (6.1446.040)
with automatic rinsing:
for FEP tubing 90 90 (6.1805.100)
75 75 Pipetting opening
for the manual addition of solutions,
closed with stopper 25 25 (6.2709.080)
76 76 Opening
in operation with MME:
for multi-mode electrode 38 38
(6.1246.020)
in operation with RDE:
for 6.2709.040 Stopper (option)
77 77 Threaded opening
for FEP tubing 39 39 (6.1805.180, already
permanently attached); inert gas supply
to meas. vessel 28 28
78 78 Threaded opening
for dummy stopper 42 42 (6.1446.040)
79 79 Opening
for reference electrode 43 43 (6.0728.020
Ag/AgCl reference system and
6.1245.010 Electrolyte vessel)
80 80 Threaded opening
for nipple 44 44 (6.2730.030) with dummy
stopper or 4-way microtip 47 47
(6.1824.000)
81 81 Opening
in operation with MME:
for stirrer, comprising drive shaft 45 45
(6.1246.010) and stirrer tip 63 63
(6.1204.090)
in operation with RDE:
for rotating disk electrode (option),
comprising drive shaft 121 121 (6.1246.000)
and electrode tip 120 120 (6.1204.XXX)
82 82 Threaded opening
for FEP tubing 57 57 (6.1805.180, already
permanently attached); inert gas supply
for tapping mechanism
83 83 Threaded opening
for FEP tubing 56 56 (6.1805.090, already
perm. attached); inert gas lead-off
84 84 Threaded opening
for FEP tubing 39 39 (6.1805.180, already
permanently attached); inert gas supply
from gas wash bottle to measuring
vessel 28 28
85 85 Threaded opening
for FEP tubing 53 53 (6.1805.040, already
permanently attached); inert gas supply
to gas wash bottle 27 27
86 86 Opening
for feedthrough of tubing connections of
4-way microtip 47 47 (6.1824.000)
87 87 Threaded opening
for FEP tubing 89 89 (6.1805.180); waste
solution lead-off
88 88 Threaded opening
for FEP tubing 55 55 (6.1805.090, already
permanently attached); waste solution
supply from gas wash bottle to waste
