5.3.3 DOSIMATS
746 VA Trace Analyzer / 747 VA Stand
5-37
5.3.3 DOSIMATS
DOSIMATS
A This dialog page is used for manual operation of the 685
Dosimats and 700 Dosinos attached to the 746 VA Trace
Analyzer.
If two rinsing Dosinos are attached to the 746 VA Trace Analyzer
(see section 3.10.5 and section 3.5.4), the Dosinos
#3
and
#4
will
not be displayed on this page.
If one of the Dosimats/Dosinos is active, the status message
* BUSY *
appears in the title line.
DOSIMATS
Dosimat/Dosino #1 #2 #3 #4
ДДДДДДДДДДДДДД ДДДДДДДДДДДДДД ДДДДДДДДДДДДД ДДДДДДДДДДДДД ДДДДДДДДДДДДД ДДДДДДДДДДДДД ДДДДДДДДДДДДД ДДДДДДДДДДДДД ДДДДДДДДДДДДД ДДДДДДДДДДДДД
V.display XXXXXX mL XXXXXX mL XXXXXX mL XXXXXX mL
V.burette XX mL XX mL XX mL XX mL
Type XXX XXX XXX XXX
Position XXXXXXXX XXXXXXXX XXXXXXXX XXXXXXXX
Gen.settings
ДДДДДДДДДДДДДД ДДДДДДДДДДДДДД
Dosing rate ........L/min ........L/min ........L/min ........L/min
Filling rate ........L/min ........L/min ........L/min ........L/min
V.init ...... mL ...... mL ...... mL ...... mL
V.tube in ...... mL ...... mL ...... mL ...... mL
V.tube out ...... mL ...... mL ...... mL ...... mL
Dil.settings
ДДДДДДДДДДДДДД ДДДДДДДДДДДДДД
C.init std ........g/L ........g/L ........g/L ........g/L
C.end dilution ........g/L ........g/L ........g/L ........g/L
V.end dilution ...... mL ...... mL ...... mL ...... mL
Modify
column
Modify
line
Empty
Dosimat
Dos
V.init
Exchange
position
Prime
Dosimat
Fill
Dosimat
>>
Modify
column
Modify
line
Default
values
Start
dilution
Exchange
all
Prime
all
Fill
all
>>
Softkeys Meaning
Modify
column
Modify parameters column-by-column
Modify
line
Modify parameters line-by-line
Empty
Dosimat
Empty 700 Dosino
The burette cylinder of the selected Dosino and all connecting tubing
up to the measuring vessel are emptied.
This softkey has no function with 685 Dosimats.
