27-14

DS785UM1

Copyright 2007 Cirrus Logic

IDE Interface
EP93xx User’s Guide

2

7

2

7

27

IDEDataIn

Address:

0x800A_0014 - Read Only

Default:

0x0000_0000

Definition:

In PIO mode read operation, this register is the Input Data Registers,
containing the register contents or the data read from the device. The register
is loaded from the DD pins at the positive edge of the DIORn signal. The
register is read only in this operation. In MDMA and UDMA data-in operations,
this register is an exact copy of the data in the input buffer to be transferred
through DMA. The register is read only in these operations. Any write to this
register is ignored.

Bit Descriptions:

IDEDD:

IDE input data in PIO read, data in input buffer in MDMA
and data at the head of input buffer in UDMA mode.

IDEMDMADataOut

Address:

0x800A_0018 - Write Only (should be written by the DMA controller only)

Default:

0x0000_0000

Definition:

In MDMA data-out operations, this register contains the data in the output
buffer to be transferred to the device. The data is written into this register by
the DMA controller. This register should only be addressed and written by the

31

30

29

28

27

26

25

24

23

22

21

20

19

18

17

16

IDEDD

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

IDEDD

31

30

29

28

27

26

25

24

23

22

21

20

19

18

17

16

IDEDD

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

IDEDD
