I 2 S Controller
EP93xx User’s Guide
2
1
2
1
21
I2SRX1Rt
Address:
0x8082_004C - Read Only
Default:
0x0000_0000
Definition:
Receive right data word for channel 1.
Bit Descriptions:
i2s_rx1_right: Receive right data word for channel 1.
I2SRX2Lft
Address:
0x8082_0050 - Read Only
Default:
0x0000_0000
Definition:
Receive left data word for channel 2.
Bit Descriptions:
i2s_rx2_left: Receive left data word for channel 2.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
i2s_rx1_right
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
i2s_rx1_right
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
i2s_rx2_left
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
i2s_rx2_left
