Cirrus Logic EP93xx User Manual
Page 589

DS785UM1
16-13
Copyright 2007 Cirrus Logic
UART3 With HDLC Encoder
EP93xx User’s Guide
1
6
1
6
16
0:
Must be written as “0”.
UART3HDLCCtrl
Address:
0x808E_020C - Read/Write
Default:
0x0000_0000
Definition:
HDLC Control Register
Bit Descriptions:
RSVD:
Reserved. Unknown During Read.
CMAS:
Clock Master:
1 - Transmitter and/or receiver use 1x clock generated by
the internal transmitter.
0 - Transmitter and/or receiver use 1x clock generated
externally.
TXCM:
Transmit Clock Mode.
1 - Generate 1x clock when in synchronous HDLC mode
using NRZ encoding.
0 - Do not generate clock.
This bit has no effect unless TXENC is clear and
synchronous HDLC is enabled.
RXCM:
Receive Clock Mode.
1 - Use external 1x clock when in synchronous HDLC
mode using NRZ encoding.
0 - Do not use external clock.
This bit has no effect unless RXENC is clear and
synchronous HDLC is enabled.
TXENC:
Transmit Encoding method.
1 - Use Manchester bit encoding.
0 - Use NRZ bit encoding.
This bit has no effect unless synchronous HDLC is
enabled
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
RSVD
CMAS
TXCM
RXCM
TXENC
RXENC
SYNC
TFCEN
TABEN
RFCEN
RILEN
RFLEN
RTOEN
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
FLAG
CRCN
CRCApd
IDLE
AME
RSVD
RXE
TXE
TUS
CRCE
CRCS
