Page 224
7-42
DS785UM1
Copyright 2007 Cirrus Logic
Raster Engine With Analog/LCD Integrated Timing and Interface
EP93xx User’s Guide
7
7
7
Horizontal Frame Timing Registers
HClkTotal
Address: 0x8003_0010
Default: 0x0000_0000
Definition: Total pixel clocks that compose a horizontal line
Bit Descriptions:
RSVD:
Reserved - Unknown during read
TOTAL:
Total - Read/Write
The HClk Total timing register contains the total number of
clocks for a horizontal video line including synchronization,
blanking, and active clocks. This value is used to preset
the Horizontal down counter. Please refer to video
signalling timing diagrams in
HSyncStrtStop
Address: 0x8003_0014
Default: 0x0000_0000
Definition: HorizontaL Sync Start/Stop Register
Bit Descriptions:
RSVD:
Reserved - Unknown during read
STOP:
Stop - Read/Write
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
RSVD
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
RSVD
TOTAL
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
RSVD
STOP
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
RSVD
STRT
