System Controller
EP93xx User’s Guide

MIRClkDiv

Address:

0x8093_0088 - Read/Write, Software locked

Default:

0x0000_0000

Definition:

Configures MIR clock for the MIR IrDA. Selects input to MIR clock dividers
from either PLL1 or PLL2, and defines a programmable divide value.

Bit Descriptions:

RSVD:

Reserved. Unknown During Read.

MENA:

Enable MIR_CLK divider.

ESEL:

External clock source select.
0 - Use the external XTALI clock input as the clock source.
1 - Use one of the internal PLLs selected by PSEL as the
clock source.

PSEL:

PLL source select.
1 - Select PLL2 as the clock source.
0 - Select PLL1 as the clock source.

PDIV:

Pre-divider value. Generates divide by 2, 2.5, or 3 from the
clock source.
00 - Disable clock
01 - Divide-by-2
10 - Divide-by-2.5
11 - Divide-by-3

MDIV:

MIR_CLK divider value. Forms a divide-by-N of the pre-
divide clock output. MIR_CLK is the source clock divided
by PDIV divided by N.

RSVD

MENA

ESEL

PSEL

RSVD

PDIV

RSVD

MDIV
