Cirrus Logic EP93xx - Manual (Page 357)

DS785UM1 9-55
Copyright 2007 Cirrus Logic
1/10/100 Mbps Ethernet LAN Controller
EP93xx User’s Guide
9
9
9
TXCollCnt
Address:
0x8001_0070 - Read Only
Chip Reset:
0x0000_0000
Soft Reset:
0x0000_0000
Definition:
Transmit Collision Count Register
Bit Descriptions:
RSVD: Reserved. Unknown During Read.
TXC: Transmit Collision Count. The transmit collision count
records the total number of collisions experienced on the
transmit interface, including late collisions. When the most
significant bit of the count is set, an optional interrupt may
be generated. The register is cleared automatically
following a read and writing to the register will have no
effect.
RXMissCnt
Address:
0x8001_0074 - Read Only
Chip Reset:
0x0000_0000
Soft Reset:
0x0000_0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TXC
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RMC
