6-4 DS785UM1
Copyright 2007 Cirrus Logic
Vectored Interrupt Controller
EP93xx User’s Guide
6
6
6
6.1.3 Interrupt Details
Details of the interrupts described in Table 6-1 are:
COMMRX ARM Communication Channel Receive. When high,
COMMRX indicates that the communications channel
receive buffer contains data waiting to be read by the ARM
Core. Refer to the ARM Technical Reference Manual.
COMMTX ARM Communication Channel Transmit. When high
COMMTX indicates that the communications channel
transmit buffer is empty. Refer to the ARM Technical
Reference Manual.
32 INT_EXT[0] External Interrupt 0
33 INT_EXT[1] External Interrupt 1
34 INT_EXT[2] External Interrupt 2
35 TINTR 64 Hz Tick Interrupt
36 WEINT Watchdog Expired Interrupt
37 INT_RTC RTC Interrupt
38 INT_IrDA IrDA Interrupt
39 INT_MAC Ethernet MAC Interrupt
40 - Reserved
41 INT_PROG Raster Programmable Interrupt
42 CLK1HZ 1 Hz Clock Interrupt
43 V_SYNC Video Sync Interrupt
44 INT_VIDEO_FIFO Raster Video FIFO Interrupt
45 INT_SSP1RX SSP Receive Interrupt
46 INT_SSP1TX SSP Transmit Interrupt
47 - Reserved
48 - Reserved
49 - Reserved
50 - Reserved
51 TC3UI TC3 under flow interrupt (Timer Counter 3)
52 INT_UART1 UART 1 Interrupt
53 SSPINTR Synchronous Serial Port Interrupt
54 INT_UART2 UART 2 Interrupt
55 INT_UART3 UART 3 Interrupt
56 USHINTR USB Host Interrupt
57 INT_PME Ethernet MAC PME Interrupt
58 INT_DSP ARM Core Interrupt
59 GPIOINTR GPIO Combined interrupt
60 I2SINTR I2S Block Combined interrupt
61 - Unused
62 - Unused
63 - Unused
Table 6-1. Interrupt Configuration
VIC Interrupt
Source
Name Description
