Definition:
The Load register contains the initial value of the timer and is also used as the
reload value in periodic timer mode. The timer is loaded by writing to the Load
register when the timer is disabled. The Timer Value register is updated with
the Timer Load value as soon as the Timer Load register is written to. The
Load register should not be written to after the Timer is enabled as this causes
the Timer Value register to be updated with an undetermined value.
Bit Descriptions:
Load:
Initial load value of the timer.
Timer1Value,
Timer2Value
Address:
Timer1 - 0x8081_0004 - Read Only
Timer2 - 0x8081_0024 - Read Only
Reset Value:
0x0000_0000
Definition:
The Value location gives the current value of the timer. When the Timer Load
register is written to, the Value register is also updated with this Load value.
Bit Descriptions:
RSVD:
Reserved. Unknown During Read.
Value:
Current value of the timer.
Timer3Value
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
RSVD
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Value
