1/10/100 Mbps Ethernet LAN Controller
EP93xx User’s Guide
9
9
9
TXStsQCurLen
Address:
0x8001_00C6 - Read/Write. Note half word alignment.
Chip Reset:
0x0000_0000
Soft Reset:
Unchanged
Definition:
Transmit Status Queue Current Length. The Transmit Status Queue Current
Length defines the number of bytes between the Transmit Status Current
Address and the end of the transmit status queue. This value is used internally
to wrap the pointer back to the start of the queue. The register should not
normally be written.
Bit Descriptions:
RSVD: Reserved. Unknown During Read.
TSQCL: Transmit Status Queue Current Length.
TXStsQCurAdd
Address:
0x8001_00C8 - Read/Write
Chip Reset:
0x0000_0000
Soft Reset:
Unchanged
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TSQCL
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSQCA
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TSQCA
