IDE Interface
EP93xx User’s Guide
2
7
2
7
27
For a Write Operation.
1. Write out the register value.
2. Delay as follows, based on the PIO mode.
PIO Mode 0 - Delay for 70 ns.
PIO Mode 1 - Delay for 50 ns.
PIO Mode 2 - Delay for 30 ns
PIO Mode 3 - Delay for 30 ns
PIO Mode 4 - Delay for 25 ns
3. Bring DIOWn high.
4. Delay as follows, based on the PIO mode.
PIO Mode 0 - Delay for 290 ns.
PIO Mode 1 - Delay for 290 ns
PIO Mode 2 - Delay for 290 ns
PIO Mode 3 - Delay for 80 ns
PIO Mode 4 - Delay for 70 ns
5. Bring DIOWn low.
6. Delay as follows, based on the PIO mode before the next read or write can occur.
PIO Mode 0 - 240 ns.
PIO Mode 1 - 50 ns
PIO Mode 2 - 20 ns
PIO Mode 3 - 70 ns
PIO Mode 4 - 25 ns
Minimum total cycle time for the various PIO modes is as follows:
PIO Mode 0 - 600 ns
PIO Mode 1 - 383 ns
PIO Mode 2 - 330 ns
PIO Mode 3 - 180 ns
PIO Mode 4 - 120 ns
You must also setup IDECFG and WST as follows, according to the PIO mode:
PIO Mode 0 - Delay for 30 ns
PIO Mode 1 - Delay for 20 ns
PIO Mode 2 - Delay for 15 ns
PIO Mode 3 - Delay for 10 ns
PIO Mode 4 - Delay for 5 ns
27.2.3 MDMA Operations
For MDMA operations, DMA commands are set up using PIO operations by the host. The
registers IDEMDMADataOut and IDEMDMADataIn act as the 1-deep buffer for write and
read operations respectively. The state machine sets up the necessary signals including the
DMA request to the DMA controller.
