Universal Serial Bus Host Controller
EP93xx User’s Guide
1
1
1
1
11
HcRhPortStatusx
Address:
HcRhPortStatus1 - 0x8002_0054,
HcRhPortStatus2 - 0x8002_0058,
HcRhPortStatus3 - 0x8002_005C
Default:
0x0000_0100
Definition:
Control/status for root hub port 1, 2, and 3 respectively
Bit Descriptions:
CCS: (READ) CurrentConnectStatus: This bit reflects the current
state of the downstream port.
0 = no device connected
1 = device connected
(WRITE) ClearPortEnable: The HCD writes a “1” to this bit
to clear the PortEnableStatus bit. Writing a “0” has no
effect. The CurrentConnectStatus is not affected by any
write.
Note: This bit is always read “1” when the attached device is nonremovable
(DeviceRemoveable.NDP).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD PRSC OCIC PSSC PESC CSC
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD LSDA PPS RSVD PRS POCI PSS PES CCS
