DS785UM1 14-31
Copyright 2007 Cirrus Logic
UART1 With HDLC and Modem Control Signals
EP93xx User’s Guide
1
4
1
4
14
Default:
0x0000_0000
Definition:
HDLC Address Match Value
Bit Descriptions:
AMV: Address match value. Supports 8-bit and 16-bit address
matching. If UART1HDLCCtrl.AME[1:0] is 00b or 11b, this
register is not used.
UART1HDLCAddMask
Address:
0x808C_0214 - Read/Write
Default:
0x0000_0000
Definition:
HDLC Address Mask
Bit Descriptions:
AMSK: Address mask value. Supports 8-bit and 16-bit address
masking. If UART1HDLCCtrl.AME[1:0] is 00b or 11b, this
register is not used.
UART1HDLCRXInfoBuf
Address:
0x808C_0218 - Read Only
Default:
0x0000_0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
AMSK
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
AMSK
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD BPLLE RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD BC BFRE BROR BCRE BRAB
