Vectored Interrupt Controller
EP93xx User’s Guide
6
6
6
Definition:
Interrupt Enable Register. The VICxIntEnable register enables the interrupt
requests by unmasking the interrupt sources. On reset, all interrupts are
disabled (masked).
Bit Descriptions:
IntEnable:
Enables the interrupt request lines:
1 - Interrupt enabled. Allows interrupt request to ARM
Core.
0 - Interrupt disabled.
VICxIntEnClear
Address:
VIC1IntEnClear: 0x800B_0014 - Write Only
VIC2IntEnClear: 0x800C_0014 - Write Only
Default: Don’t Care
Definition:
Interrupt Enable Clear Register. The VICxIntEnClear register clears bits in the
VICxIntEnable register.
Bit Descriptions:
IntEnable Clear:
Clears bits in the VICxIntEnable register. Writing a bit to
“1” clears the corresponding bit in the VICxIntEnable
register. Any bits written to “0” have no effect.
VICxSoftInt
Address:
VIC1SoftInt: 0x800B_0018 - Read/Write
VIC2SoftInt: 0x800C_0018 - Read/Write
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
IntEnable Clear
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
IntEnable Clear
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
SoftInt
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
SoftInt
