8.5.2.2 8 BPP Word Layout

For a Block Copy where 4 pixels are transferred per scan line, let the starting SDRAM
address of the source image be 0x0000.

Table 8-15

shows that Pixel 2 starts at bit 16, Pixel 3

starts at bit 24, etc. The start pixel, P2, is in the word at address 0x0000 and has a beginning
bit position of 16. This makes 16 = 0x10 the value that is used for the SPEL field in the

“SRCPIXELSTRT”

Let the starting SDRAM address of the destination image be 0x0030.

Table 8-16

shows that

Pixel 2 starts at bit 16, Pixel 3 starts at bit 34, etc. The start pixel, P2, is in the word at address
0x0030 and has a beginning bit position of 16. This makes 16 = 0x10 the value that is used
for the SPEL field in the

“DESTPIXELSTRT”

The end pixel, P5, is in the word at address 0x0034 and has a beginning bit position of 8. This
makes 8 = 0x8 the value that is used for the EPEL field in the

“DESTPIXELSTRT”

Note:The word count for this example would be: 2 - 1 = 1 words, since P5 ends in the 2nd word.

So, WIDTH = 0x1 would be written to the

“BLKDESTWIDTH”

8.5.2.3 16 BPP WORD Layout

For a Block Copy where 8 pixels are transferred per scan line, let the starting SDRAM
address of the source image be 0x0000.

Table 8-17

shows that Pixel 0 starts at bit 0, Pixel 1

starts at bit 16, etc. The start pixel, P0, is in the word at address 0x0000 and has a beginning
bit position of 0. This makes 0 = 0x0 the value that is used for the SPEL field in the

“SRCPIXELSTRT”

Table 8-15. 8 BPP Memory Layout for Source Image

Address

0x0000

0x0004

Table 8-16. 8 BPP Memory Layout for Destination Image

Address

0x0030

0x0034

Table 8-17. 16 BPP Memory Layout for Source Image

Address

0x0000

0x0004

0x0008

0x000C
