Cirrus Logic EP93xx - Manual (Page 59)

DS785UM1 2-21
Copyright 2007 Cirrus Logic
ARM920T Core and Advanced High-Speed Bus (AHB)
EP93xx User’s Guide
2
2
2
0x8003_006C CursorColor1 Cursor color overlaid when cursor value is 10 N
0x8003_0070 CursorColor2 Cursor color overlaid when cursor value is 11 N
0x8003_0074 CursorXYLoc Cursor X and Y location Register N
0x8003_0078 CursorDScanLHYLoc Cursor dual scan lower half Y location Register N
0x8003_007C RasterSWLock
Software Lock Register. Register used to unlock registers that
have SWLOCK
N
0x8003_0080 - 0x8003_00FC GrySclLUTR Grayscale Look Up Table N
0x8003_0200 VidSigRsltVal Video signature result value N
0x8003_0204 VidSigCtrl Video signature Control Register N
0x8003_0208 VSigStrtStop Vertical signature bounds setup N
0x8003_020C HSigStrtStop Horizontal signature bounds setup N
0x8003_0210 SigClrStr Signature clear and store location N
0x8003_0214 ACRate LCD AC voltage bias control counter setup N
0x8003_0218 LUTSwCtrl LUT switching control Register N
0x8003_021C CursorBlinkColor1 Cursor Blink color 1 N
0x8003_0220 CursorBlinkColor2 Cursor Blink color 2 N
0x8003_0224 CursorBlinkRateCtrl Cursor Blink rate control Register N
0x8003_0228 VBlankStrtStop Vertical Blank signal Start/Stop Register N
0x8003_022C HBlankStrtStop Horizontal Blank signal Start/Stop Register N
0x8003_0230 EOLOffset End Of Line Offset value N
0x8003_0234 FIFOLevel FIFO refill level Register N
0x8003_0280 - 0x8003_02FC GrySclLUTG Grayscale Look Up Table N
0x8003_0300 - 0x8003_037C GrySclLUTB Grayscale Look Up Table N
0x8003_0400 - 0x8003_07FC ColorLUT Color Look Up Table N
0x8004_xxxx - 0x8005_xxxx Reserved
0x8006_xxxx SDRAM SDRAM Registers N
0x8006_0000 Reserved
0x8006_0004 GlConfig Control and status bits used in configuration N
0x8006_0008 RefrshTimr Set the period between refresh cycles N
0x8006_000C BootSts Reflect the state of the boot mode option pins N
0x8006_0010 SDRAMDevCfg0 Device configuration 0 N
0x8006_0014 SDRAMDevCfg1 Device configuration 1 N
0x8006_0018 SDRAMDevCfg2 Device configuration 2 N
0x8006_001C SDRAMDevCfg3 Device configuration 3 N
0x8008_xxxx SMC SMC and PCMCIA Control Registers
0x8008_0000 SMCBCR0
Bank config Register 0 (used to program characteristics of the
SRAM/ROM memory)
N
0x8008_0004 SMCBCR1
Bank config Register 1 (used to program characteristics of the
SRAM/ROM memory)
N
Table 2-8. Internal Register Map (Continued)
Address Register Name Register Description
SW
Lock
