UART1 With HDLC and Modem Control Signals
EP93xx User’s Guide
1
4
1
4
14
FE:
Framing Error. When this bit is set to 1, it indicates that the
received character did not have a valid stop bit (a valid
stop bit is “1”). This bit is cleared to 0 by a write to
UART1RXSts. In FIFO mode, this error is associated with
the character at the top of the FIFO.
UART1LinCtrlHigh
Address:
0x808C_0008 - Read/Write
Default:
0x0000_0000
Definition:
UART1 Line Control Register High. UART1LinCtrlHigh, UART1LinCtrlMid and
UART1LinCtrlLow form a single 23-bit wide register (UART1LinCtrl) which is updated on a
single write strobe generated by an UART1LinCtrlHigh write. In order to internally update the
contents of UART1LinCtrlMid or UART1LinCtrlLow, a UART1LinCtrlHigh write must always
be performed at the end.
To update the three registers there are two possible sequences:
• UART1LinCtrlLow write, UART1LinCtrlMid write and UART1LinCtrlHigh write
• UART1LinCtrlMid write, UART1LinCtrlLow write and UART1LinCtrlHigh write.
To update UART1LinCtrlLow or UART1LinCtrlMid only:
• UART1LinCtrlLow write (or UART1LinCtrlMid write) and UART1LinCtrlHigh write.
Bit Descriptions:
RSVD:
Reserved. Unknown During Read.
WLEN:
Number of bits per frame:
11 = 8 bits
10 = 7 bits
01 = 6 bits
00 = 5 bits
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
RSVD
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
RSVD
WLEN
FEN
STP2
EPS
PEN
BRK
