The X Location value written to this field specifies the
starting horizontal X location of the cursor image. The
value is compared to the horizontal pixel counter and it
should be specified to be between the active start and
active stop horizontal pixel values.
This X Location value is also used to specify the starting
location for the cursor image in the upper half of the
display when Dual Scan mode is enabled by writing
DSCAN = ‘1’ in the
register.
The cursor hardware will clip the cursor at the right edge of
the screen. To prevent cursor distortion, a new X Location
value will not be used until the next frame.
CursorDScanLHYLoc
Address: 0x8003_0078
Default: 0x0000_0000
Definition: Cursor Y Location register
Bit Descriptions:
RSVD:
Reserved - Unknown during read
CLHEN:
Cursor Lower Half Enable - Read/Write
Writing a ‘1’ to this bit specifies that some or all of the
cursor image is located in the lower half of the display.
Writing a ‘0’ to this bit specifies the opposite.
0 - Hardware cursor not located in lower half of display
1 - Hardware cursor located in lower half of display
YLOC:
Y Location - Read/Write
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
RSVD
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
CLHEN
RSVD
YLOC
