Static Memory Controller
EP93xx User’s Guide
1
2
1
2
12
EBIBRKDIS:
EBI Break Disable - Read/Write
The value written to this bit specifies the circumstances for
when the SMC will release the external memory bus:
0 - The SMC releases the external memory bus at the end
of each access to this memory bank
1 - The SMC releases the external memory bus after it has
completed all pending accesses to this memory bank
12.6.2 PCMCIA Configuration Registers (EP9315 Processor Only)
The SMC has additional functionality to support a PC-card in Memory Bank 4. Memory Bank
4 has three registers to control wait-states and device width for attribute, common memory
and IO address spaces; and a single PCMCIA control register to provide global control for the
card.
PCAttribute
Address: 0x8008_0020 - Read/Write
Default: 0x0000_0000
Definition: PC Card Attribute register
Bit Descriptions:
RSVD:
Reserved - Unknown During Read
WA:
Attribute Space Width - Read/Write
The value written to this bit specifies the bus-width of the
Attribute space:
0 - 8-bit wide Attribute space
1 - 16-bit wide Attribute space
AA:
Attribute Space Access time - Read/Write
The value written to this field specifies the minimum
‘number of HCLK cycles, minus 1’ that the data strobe,
MCDAENn
,
is asserted during a Read or Write access.
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
WA
RSVD
AA
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
RSVD
HA
PA
