Watchdog Timer
EP93xx User’s Guide
1
9
1
9
19
WDStatus
Address:
0x8094_0004 - Read/Write
Default:
0x0000_0000
Definition:
Watchdog status storage register. It can be used for storing your own status,
and it can only be cleared by power-on-reset.
Bit Descriptions:
RSVD: Reserved. Unknown during read.
STAT: Watchdog Status bits. This is a watchdog status storage
register that is not cleared by any resets other than power-
on-reset and PWR_RESETn. The system can be reset by
a three-key reset, a user reset, or a watchdog reset
without losing the contents of this register.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD STAT
