Static Memory Controller
EP93xx User’s Guide
1
2
1
2
12
Table 12-6. Accesses to 8-Bit Attribute / Common / IO Memory
Common / IO
Memory Access
Attribute
Memory Access
Access
Byte #
In Word
PC_A[25:0] nPC_CE2 nPC_CE1 D15-D8 D7-D0 D15-D8 D7-D0
Word
(4 transfers
required)
0 [25:2],x,0 0 0 - [7:0] - [7:0]
1 [25:2],x,1 1 0 - [15:8] - Invalid
2 [25:2],x,0 0 0 - [23:16] - [23:16]
3 [25:2],x,1 1 0 - [31:24] - Invalid
Lower
Half-Word
(2 transfers
required)
0
[25:2],x,0
0 0 - [7:0] - [7:0]
1
[25:2],x,1 1 0 - [15:8] - Invalid
Upper
Half-Word
(2 transfers
required)
2 [25:2],x,0
0 0 - [23:16] - [23:16]
3 [25:2],1,1 1 0 - [31:24] - Invalid
Byte 0 [25:2],x,0 0 0 - [7:0] - [7:0]
Byte 1 [25:2],x,1 1 0 - [15:8] - Invalid
Byte 2 [25:2],x,0 0 0 - [23:16] - [23:16]
Byte 3 [25:2],x,1 1 0 - [31:24] - Invalid
Table 12-7. Accesses to 16-Bit Attribute / Common / IO Memory
Common / IO
Memory Access
Attribute
Memory Access
Access
Half-Word
# IN Word
Processor
Address Bus
AD[25:0]
nPC_CE
2
nPC_CE
1
D15-D8 D7-D0 D15-D8 D7-D0
Word
(2
transfers
required)
0
AD[25:2],x,x
0 0 [15:8] [7:0] Invalid [7:0]
1 AD[25:2],x,x
0 0 [31:24] [23:16] Invalid [23:16]
Lower
Half-Word
0 AD[25:2],x,x 0 0 [15:8] [7:0] Invalid [7:0]
Upper
Half-Word
1 AD[25:2],x,x 0 0 [31:24] [23:16] Invalid [23:16]
Byte 0 0 AD[25:2],x,0 1 0 - [7:0] - [7:0]
Byte 1 0 AD[25:2],0,1 1 0 [15:8] - Invalid -
Byte 2 1 AD[25:2],x,0 1 0 - [23:16] - [23:16]
Byte 3 1 AD[25:2],x,1 1 0 [31:24] - Invalid -
