3 Operation Log Settings Dialog Box
15-10 WindO/I-NV2 User’s Manual
This section describes items and buttons on the Operation Log Settings dialog box.
3.1 Operation Log Settings Dialog Box
●
General Tab
The General tab is used to configure the events and the condition for recording.
■ Enable Operation Log Settings
Select this check box to use the Operation Log function.
■ Target Events to record
Selects the events to record. Select the check boxes for the events to record.
3 Operation Log Settings Dialog Box
HG3G HG2G-5F HG2G-5S HG2G-S HG4G HG1F HG2F HG2S HG3F HG4F
Power ON: The following items are recorded when the MICRO/I power is turned on.
Time, screen number, event name
Switch to Base Screen: The following items are recorded when the base screen is switched.
Time, user name, screen number, event name, changed to
Change Users: The following items are recorded when the user is changed.
Time, user name, screen number, event name, changed to
Change Operation Modes: The following items are recorded when the operation mode is changed.
Time, user name, screen number, event name, changed to
Press buttons: The following items are recorded when a touch switch is pressed.
Time, user name, screen number, event name, part name
Write Data to any Devices: The following items are recorded when a value is written to a device by pressing a touch
switch.
Time, user name, screen number, event name, device, changed to
Edit Data Labels: Displays the Data Labels dialog box.
The Data Labels dialog box is used to edit the text displayed in the label row and the
event names displayed in the data rows when the recorded data is output as a CSV file.
For details, refer to “Data Labels Dialog Box” on page 15-12.
