9 Potentiometer
8-148 WindO/I-NV2 User’s Manual
9.3 Properties of Potentiometer Dialog Box
This section describes items and buttons in the Properties dialog box.
●
General Tab
■ Part Name
Enter a name for the part. The maximum number is 20 characters.
■ Data Type
Select the data type to be handled by the Potentiometer.
For details, refer to Chapter 2 “1.2 Available Data” on page 2-2.
■ Minimum
Specify the minimum value that can be entered. The minimum value differs depending on the data type.
■ Maximum
Specify the maximum value that can be entered. The maximum value differs depending on the data type.
■ Destination Device
Specify the destination word device.
Click to display the Device Address Settings dialog box. For the device address configuration procedure, refer
to Chapter 2 “5.1 Device Address Settings” on page 2-67.
