2 Creating and Manipulating WindO/I-NV2 Screens
5-6 WindO/I-NV2 User’s Manual
●
Saving a screen with a different screen number
You can save the screen being edited with a different screen number.
1 Right click a screen in the Project window and then click Save Screen As.
The Save Screen As dialog box is displayed.
2 Specify the screen number after saving and click the OK button.
■ New No.
Specify the screen number (Base Screen: 1 to 3000, Popup Screen: 1 to 3015) after saving.
■ Screen Title
Enter or change the screen title. Maximum number is 40 characters.
■ Screen List
This list shows screens that have already been created.
If you specify an existing screen number and then click the OK button, an overwrite confirmation message
is displayed.
• Click the Yes button to overwrite the screen.
• Click the No button to return to the editing window without saving the screen.
