2 PLC Program Transfer Function
28-28 WindO/I-NV2 User’s Manual
●
Upload
1 Insert an SD memory card or USB flash drive in the MICRO/I.
2 Press the upper-left edge of the MICRO/I screen for three seconds or more.
The maintenance screen is displayed.
3 Press System Mode.
MICRO/I switches to system mode.
4 Press Offline.
The main menu is displayed.
HG3G HG2G-5F HG4G
SD Memory Card
PLC
MICRO/I
USB flash drive
HG3G HG2G-5F HG4G
Press and hold
3 or more seconds
MICRO/I
Maintenance
System Mode
Device Monitor
Adjust Brightness
When downloading a project configured with security to the MICRO/I, the password screen is displayed.
Select a user name and enter its password. For details, refer to Chapter 23 “User Accounts and the Security
Function” on page 23-1.
Run Simulate Offline
<< >> BRIGHTNESS 31
MAC Address 00:03:7B:F0:12:A8
2010/OCT/14/THU 14:56:44
IDEC HG G SERIES
SYSTEM MODE TOP PAGE
ENG/JPN
