C HAPTER 25 | SNMP Commands
SNMPv3 Commands
– 837 –
C OMMAND U SAGE
◆ A group sets the access policy for the assigned users.
◆ When authentication is selected, the MD5 or SHA algorithm is used as
specified in the snmp-server user command.
◆ When privacy is selected, the DES 56-bit algorithm is used for data
encryption.
◆ For additional information on the notification messages supported by
this switch, see Table 29, "Supported Notification Messages," on
page 436 . Also, note that the authentication, link-up and link-down
messages are legacy traps and must therefore be enabled in
conjunction with the snmp-server enable traps command.
E XAMPLE
Console(config)#snmp-server group r&d v3 auth write daily
Console(config)#
snmp-server user This command adds a user to an SNMP group, restricting the user to a
specific SNMP Read, Write, or Notify View. Use the no form to remove a
user from an SNMP group.
S YNTAX
snmp-server user username groupname [remote ip-address]
{v1 | v2c | v3 [encrypted] [auth {md5 | sha} auth-password
[priv des56 priv-password]]
no snmp-server user username {v1 | v2c | v3 | remote}
username - Name of user connecting to the SNMP agent.
(Range: 1-32 characters)
groupname - Name of an SNMP group to which the user is assigned.
(Range: 1-32 characters)
remote - Specifies an SNMP engine on a remote device.
ip-address - The Internet address of the remote device.
v1 | v2c | v3 - Use SNMP version 1, 2c or 3.
encrypted - Accepts the password as encrypted input.
auth - Uses SNMPv3 with authentication.
md5 | sha - Uses MD5 or SHA authentication.
auth-password - Authentication password. Enter as plain text if the
encrypted option is not used. Otherwise, enter an encrypted
password. (A minimum of eight characters is required.)
priv des56 - Uses SNMPv3 with privacy with DES56 encryption.
priv-password - Privacy password. Enter as plain text if the
encrypted option is not used. Otherwise, enter an encrypted
password.
