C HAPTER 49 | IP Routing Commands
Open Shortest Path First (OSPFv2)
– 1474 –
E XAMPLE
Console#show ip rip
Codes: R - RIP, Rc - RIP connected, Rs - RIP static,
C - Connected, S - Static, O - OSPF
Network Next Hop Metric From Interface Time
Rc 192.168.0.0/24 1 VLAN1 01:57
Console#show ip rip interface vlan 1
Interface: vlan1
Routing Protocol: RIP
Receive RIPv1 and RIPv2 packets
Send RIPv1 Compatible
Passive interface: Disabled
Authentication mode: (None)
Authentication string: (None)
Split horizon: Enabled with Poisoned Reverse
IP interface address: 192.168.0.2/24
Console#
O PEN S HORTEST P ATH F IRST (OSPF V 2)
Table 205: Open Shortest Path First Commands
Command Function Mode
General Configuration
router ospf Enables or disables OSPFv2 GC
compatible rfc1583 Calculates summary route costs using RFC 1583 (early
OSPFv2)
RC
default-information
originate
Generates a default external route into an autonomous
system
RC
router-id Sets the router ID for this device RC
timers spf Configures the delay after a topology change and the
hold time between consecutive SPF calculations
RC
clear ip ospf process Clears and restarts the OSPF routing process PE
Route Metrics and Summaries
area default-cost Sets the cost for a default summary route sent into a
stub or NSSA
RC
area range Summarizes routes advertised by an ABR RC
auto-cost reference-
bandwidth
Calculates default metrics for an interface based on
bandwidth
RC
default-metric Sets the default metric for external routes imported
from other protocols
RC
redistribute Redistribute routes from one routing domain to
another
RC
summary-address Summarizes routes advertised by an ASBR RC
Area Configuration
area nssa Defines a not-so-stubby that can import external
routes
RC
