C HAPTER 4 | Basic Management Tasks
Displaying Bridge Extension Capabilities
– 133 –
P ARAMETERS
The following parameters are displayed:
◆ Jumbo Frame – Configures support for jumbo frames.
(Default: Disabled)
W EB I NTERFACE
To configure support for jumbo frames:
1. Click System, then Capability.
2. Enable or disable support for jumbo frames.
3. Click Apply.
Figure 5: Configuring Support for Jumbo Frames
D ISPLAYING B RIDGE E XTENSION C APABILITIES
Use the System > Capability page to display settings based on the Bridge
MIB. The Bridge MIB includes extensions for managed devices that support
Multicast Filtering, Traffic Classes, and Virtual LANs. You can access these
extensions to display default settings for the key variables.
CLI R EFERENCES
◆ "GVRP and Bridge Extension Commands" on page 1108
P ARAMETERS
The following parameters are displayed:
◆ Extended Multicast Filtering Services – This switch does not
support the filtering of individual multicast addresses based on GMRP
(GARP Multicast Registration Protocol).
◆ Traffic Classes – This switch provides mapping of user priorities to
multiple traffic classes. (Refer to "Class of Service" on page 275 .)
◆ Static Entry Individual Port – This switch allows static filtering for
unicast and multicast addresses. (Refer to "Setting Static Addresses"
on page 235 .)
◆ VLAN Version Number – Based on IEEE 802.1Q, “1” indicates Bridges
that support only single spanning tree (SST) operation, and “2”
indicates Bridges that support multiple spanning tree (MST) operation.
