C HAPTER 15 | Multicast Filtering
Multicast VLAN Registration
– 560 –
P ARAMETERS
These parameters are displayed:
Configure Profile
◆ Profile Name – The name of a profile containing one or more MVR
group addresses. (Range: 1-20 characters)
◆ Start IP Address – Starting IP address for an MVR multicast group.
(Range: 224.0.1.0 - 239.255.255.255)
◆ End IP Address – Ending IP address for an MVR multicast group.
(Range: 224.0.1.0 - 239.255.255.255)
Associate Profile
◆ Domain ID – An independent multicast domain. (Range: 1-5)
◆ Profile Name – The name of a profile to be assigned to this domain.
(Range: 1-20 characters)
W EB I NTERFACE
To configure an MVR group address profile:
1.
Click Multicast, MVR.
2.
Select Configure Profile from the Step list.
3.
Select Add from the Action list.
4. Enter the name of a group profile to be assigned to one or more
domains, and specify a multicast group that will stream traffic to
participating hosts.
5. Click Apply.
Figure 328: Configuring an MVR Group Address Profile
