C HAPTER 40 | Class of Service Commands
Priority Commands (Layer 2)
– 1156 –
queue cos-map This command assigns class of service (CoS) values to the priority queues
(i.e., hardware output queues 0 - 7). Use the no form set the CoS map to
the default values.
S YNTAX
queue cos-map queue_id [cos1 ... cosn]
no queue cos-map
queue_id - The ID of the priority queue.
Ranges are 0 to 7, where 7 is the highest priority queue.
cos1 ... cosn - The CoS values that are mapped to the queue ID. It
is a space-separated list of numbers. The CoS value is a number
from 0 to 7, where 7 is the highest priority.
D EFAULT S ETTING
This switch supports Class of Service by using eight priority queues, with
Weighted Round Robin queuing for each port. Eight separate traffic classes
are defined in IEEE 802.1p. The default priority levels are assigned
according to recommendations in the IEEE 802.1p standard as shown
below.
C OMMAND M ODE
Interface Configuration (Ethernet, Port Channel)
C OMMAND U SAGE
◆ CoS values assigned at the ingress port are also used at the egress
port.
◆ This command sets the CoS priority for all interfaces.
E XAMPLE
The following example shows how to change the CoS assignments to a
one-to-one mapping:
Console(config)#interface ethernet 1/1
Console(config-if)#queue cos-map 0 0
Console(config-if)#queue cos-map 1 1
Console(config-if)#queue cos-map 2 2
Console(config-if)#exit
Console#show queue cos-map ethernet 1/1
Information of Eth 1/1
CoS Value: 0 1 2 3 4 5 6 7
Priority Queue: 2 0 1 3 4 5 6 7
Console#
Table 134: Default CoS Priority Levels
Priority 0 1 2 3 4 5 6 7
Queue 2 0 1 3 4 5 6 7
