LevelOne GTL-2691 - Manual (Page 1461)

C HAPTER 49 | IP Routing Commands
Routing Information Protocol (RIP)
– 1461 –
maximum-prefix This command sets the maximum number of RIP routes allowed by the
system. Use the no form to restore the default setting.
S YNTAX
maximum-prefix maximum-routes
no maximum-prefix
maximum-routes - The maximum number of RIP routes which can
be installed in the routing table. (Range: 1-7168)
D EFAULT S ETTING
1024
C OMMAND M ODE
Router Configuration
C OMMAND U SAGE
All the learned RIP routes may not be copied to the hardware tables in
ASIC for fast data forwarding because of hardware resource limitations.
E XAMPLE
Console(config-router)#maximum-prefix 1024
Console(config-router)#
neighbor This command defines a neighboring router with which this router will
exchange routing information. Use the no form to remove an entry.
S YNTAX
[no] neighbor ip-address
ip-address - IP address of a neighboring router.
D EFAULT S ETTING
No neighbors are defined.
C OMMAND M ODE
Router Configuration
C OMMAND U SAGE
◆ This command can be used to configure a static neighbor (specifically
for point-to-point links) with which this router will exchange routing
information, rather than relying on broadcast or multicast messages
generated by the RIP protocol.
◆ Use this command in conjunction with the passive-interface command
to control the routing updates sent to specific neighbors.
