C HAPTER 5 | Interface Configuration
Trunk Configuration
– 186 –
D ISPLAYING LACP
S ETTINGS AND S TATUS
FOR THE R EMOTE S IDE
Use the Interface > Trunk > Dynamic (Configure Aggregation Port - Show
Information - Neighbors) page to display the configuration settings and
operational state for the remote side of a link aggregation.
CLI R EFERENCES
◆ "show lacp" on page 1025
P ARAMETERS
These parameters are displayed:
W EB I NTERFACE
To display LACP settings and status for the remote side:
1.
Click Interface, Trunk, Dynamic.
2.
Select Configure Aggregation Port from the Step list.
3.
Select Show Information from the Action list.
4.
Click Neighbors.
5.
Select a group member from the Port list.
Table 10: LACP Internal Configuration Information
Parameter Description
Partner Admin
System ID
LAG partner’s system ID assigned by the user.
Partner Oper System
ID
LAG partner’s system ID assigned by the LACP protocol.
Partner Admin
Port Number
Current administrative value of the port number for the protocol
Partner.
Partner Oper
Port Number
Operational port number assigned to this aggregation port by the
port’s protocol partner.
Port Admin Priority Current administrative value of the port priority for the protocol
partner.
Port Oper Priority Priority value assigned to this aggregation port by the partner.
Admin Key Current administrative value of the Key for the protocol partner.
Oper Key Current operational value of the Key for the protocol partner.
Admin State Administrative values of the partner’s state parameters. (See
preceding table.)
Oper State Operational values of the partner’s state parameters. (See preceding
table.)
