C HAPTER 3 | Using the Web Interface
Navigating the Web Browser Interface
– 110 –
Statistics Shows Interface, Etherlike, RMON and Utilization trunk statistics 168
Chart Shows Interface, Etherlike, RMON and Utilization trunk statistics 168
Load Balance Sets the load-distribution method among ports in aggregated links 187
sFlow Configures flow sampling for source and destination ports 189
Traffic Segmentation
Configure Global Enables traffic segmentation globally 191
Configure Session Configures the uplink and down-link ports for a segmented group
of ports
193
Add Assign the downlink and uplink ports to use in a segmented group 193
Show Shows the assigned ports and direction (uplink/downlink) 193
VLAN Trunking Allows unknown VLAN groups to pass through the specified
interface
195
VLAN Virtual LAN
Static
Add Creates VLAN groups 200
Show Displays configured VLAN groups 200
Modify Configures group name and administrative status 200
Edit Member by VLAN Specifies VLAN attributes per VLAN 202
Edit Member by Interface Specifies VLAN attributes per interface 202
Edit Member by Interface Range Specifies VLAN attributes per interface range 202
Dynamic
Configure General Enables GVRP VLAN registration protocol globally 207
Configure Interface Configures GVRP status and timers per interface 207
Show Dynamic VLAN
Show VLAN Shows the VLANs this switch has joined through GVRP 207
Show VLAN Member Shows the interfaces assigned to a VLAN through GVRP 207
Private
Configure VLAN
Add Creates primary or community VLANs 211
Show Display configured primary and community VLANs 211
Add Community VLAN Associates a community VLAN with a primary VLAN 212
Show Community VLAN Shows the community VLANs associated with a primary VLAN 212
Configure Interface Sets the private VLAN interface type, and associates the
interfaces with a private VLAN 213
Tunnel IEEE 802.1Q (QinQ) Tunneling 215
Configure Global Sets tunnel mode for the switch 219
Configure Service Sets a CVLAN to SPVLAN mapping entry 220
Configure Interface Sets the tunnel mode for any participating interface 222
Table 6: Switch Main Menu (Continued)
Menu Description Page
