C HAPTER 20 | Unicast Routing
Configuring the Routing Information Protocol
– 666 –
Figure 416: Configuring a Network Interface for RIP
To show the network interface settings configured for RIP:
1.
Click Routing Protocol, RIP, Interface.
2.
Select Show from the Action list.
Figure 417: Showing RIP Network Interface Settings
D ISPLAYING RIP
I NTERFACE S ETTINGS
Use the Routing Protocol > RIP > Statistics (Show Interface Information)
page to display information about RIP interface configuration settings.
CLI R EFERENCES
◆ "show ip rip" on page 1473
P ARAMETERS
These parameters are displayed:
◆ Interface – Source IP address of RIP router interface.
◆ Auth Type – The type of authentication used for exchanging RIPv2
protocol messages.
◆ Send Version – The RIP version to sent on this interface.
◆ Receive Version – The RIP version accepted on this interface.
◆ Rcv Bad Packets – Number of bad RIP packets received.
