C HAPTER 49 | IP Routing Commands
Open Shortest Path First (OSPFv3)
– 1518 –
C OMMAND U SAGE
◆ This command is used to enable an OSPFv3 routing process, and to
enter router configuration mode.
◆ The process-name is only used on the local router to distinguish
between different routing processes. It should not be confused with the
instance-id configured with the ipv6 router ospf area command which is
used to distinguish between different routing processes running on the
same link-local network segment.
E XAMPLE
Console(config)#router ipv6 ospf tag 0
Console(config-router)#end
Console#show ipv6 ospf
Routing Process "ospf r&d" with ID 192.168.0.2
Process uptime is 1 hour 34 minutes
Supports only single TOS(TOS0) routes
SPF schedule delay 5 secs, Hold time between two SPFs 10 secs
Number of incoming concurrent DD exchange neighbors 0/5
Number of outgoing concurrent DD exchange neighbors 0/5
Number of external LSA 0. Checksum 0x000000
Number of opaque AS LSA 0. Checksum 0x000000
Number of LSA received 0
Number of areas attached to this router: 1
Area 0.0.0.0 (BACKBONE)
SPF algorithm executed 1 times
Number of LSA 2. Checksum 0x00ab4f
Console#
R ELATED C OMMANDS
ipv6 router ospf area (1528)
abr-type This command sets the criteria used to determine if this router can declare
itself an ABR and issue Type 3 and Type 4 summary LSAs. Use the no form
to restore the default setting.
S YNTAX
abr-type {cisco | ibm | standard}
no abr-type
cisco - ABR criteria and functional behavior is based on RFC 3509.
ibm - ABR criteria and functional behavior is briefly described in
RFC 3509, and fully documented in IBM Nways Multiprotocol
Routing Services (MRS) 3.3.
standard - ABR criteria and functional behavior is based on
RFC 2328.
C OMMAND M ODE
Router Configuration
