C HAPTER 42 | Multicast Filtering Commands
MVR for IPv6
– 1256 –
show mvr6
associated-profile
This command shows the profiles bound the specified domain.
S YNTAX
show mvr6 [domain domain-id] associated-profile
domain-id - An independent multicast domain. (Range: 1-5)
D EFAULT S ETTING
Displays profiles bound to all MVR domains.
C OMMAND M ODE
Privileged Exec
E XAMPLE
The following displays the profiles bound to domain 1:
Console#show mvr6 domain 1 associated-profile
Domain ID : 1
MVR Profile Name Start IPv6 Addr. End IPv6 Addr.
-------------------- ------------------------- -------------------------
rd FF00::1 FF00::9
Console#
show mvr6 interface This command shows MVR configuration settings for interfaces attached to
the MVR VLAN.
S YNTAX
show mvr6 [domain domain-id] interface
domain-id - An independent multicast domain. (Range: 1-5)
D EFAULT S ETTING
Displays configuration settings for all attached interfaces.
MVR6 Domain An independent multicast domain.
MVR6 Config Status Shows if MVR is globally enabled on the switch.
MVR6 Running Status Indicates whether or not all necessary conditions in the MVR
environment are satisfied. (Running status is true as long as MVR
Status is enabled, and the specified MVR VLAN exists, and a source
port with a valid link has been configured (using the mvr6 type
command.)
MVR6 Multicast VLAN Shows the VLAN used to transport all MVR multicast traffic.
MVR Current Learned
Groups
The current number of MVR group addresses
MVR6 Upstream
Source IP
The source IP address assigned to all upstream control packets.
Table 155: show mvr6 - display description (Continued)
Field Description
