C HAPTER 16 | IP Configuration
Setting the Switch’s IP Address (IP Version 6)
– 579 –
C ONFIGURING THE
IP V 6 D EFAULT
G ATEWAY
Use the IP > IPv6 Configuration (Configure Global) page to configure an
IPv6 default gateway for the switch.
CLI R EFERENCES
◆ "ipv6 default-gateway" on page 1408
P ARAMETERS
These parameters are displayed:
◆ Default Gateway – Sets the IPv6 address of the default next hop
router to use when no routing information is known about an IPv6
address.
■
If no routing protocol is enabled or static route defined, you must
define a gateway if the target device is located in a different subnet.
■
If a routing protocol is enabled ( page 649 ), you can still define a
static route ( page 633 ) to ensure that traffic to the designated
address or subnet passes through a preferred gateway.
■
An IPv6 default gateway can only be successfully set when a
network interface that directly connects to the gateway has been
configured on the switch.
W EB I NTERFACE
To configure an IPv6 default gateway for the switch:
1.
Click IP, IPv6 Configuration.
2.
Select Configure Global from the Action list.
3. Enter the IPv6 default gateway.
4.
Click Apply.
Figure 343: Configuring the IPv6 Default Gateway
C ONFIGURING IP V 6
I NTERFACE S ETTINGS
Use the IP > IPv6 Configuration (Configure Interface) page to configure
general IPv6 settings for the selected VLAN, including explicit configuration
of a link local interface address, the MTU size, and neighbor discovery
protocol settings for duplicate address detection and the neighbor
solicitation interval.
CLI R EFERENCES
◆ "IPv6 Interface" on page 1407
