HAPTER

| Multicast Routing

Configuring PIM for IPv4

– 726 –

◆

Priority – Priority value used by this BSR candidate.

◆

Hash Mask Length – The number of significant bits used in the

multicast group comparison mask by this BSR candidate.

◆

Expire – The time before the BSR is declared down.

◆

Role – Candidate or non-candidate BSR.

◆

State

– Operation state of BSR includes:

■

No information – No information is stored for this device.

■

Accept Any – The router does not know of an active BSR, and will

accept the first bootstrap message it sees as giving the new BSR's

identity and the RP-set.

■

Accept Preferred – The router knows the identity of the current

BSR, and is using the RP-set provided by that BSR. Only bootstrap

messages from that BSR or from a C-BSR with higher weight than

the current BSR will be accepted.

■

Candidate BSR – Bidding in election process.

■

Pending-BSR – The router is a candidate to be the BSR for the RP-

set. Currently, no other router is the preferred BSR, but this router

is not yet the elected BSR.

■

Elected BSR – Elected to serve as BSR.

NTERFACE

To display information about the BSR:

Click Multicast, Multicast Routing, SM.

Select Show Information from the Step list.

Select Show BSR Router from the Action list.

13. These parameters are based on RFC 5059.
