C
HAPTER
11
| Quality of Service
Attaching a Policy Map to a Port
– 301 –
A
TTACHING
A
P
OLICY
M
AP
TO
A
P
ORT
Use the Traffic > DiffServ (Configure Interface) page to bind a policy map
to an ingress port.
CLI R
EFERENCES
◆
"Quality of Service Commands" on page 1169
C
OMMAND
U
SAGE
◆
First define a class map, define a policy map, and bind the service
policy to the required interface.
◆
Only one policy map can be bound to an interface.
◆
The switch does not allow a policy map to be bound to an interface for
egress traffic.
P
ARAMETERS
These parameters are displayed:
◆
Port – Specifies a port.
◆
Ingress – Applies the selected rule to ingress traffic.
W
EB
I
NTERFACE
To bind a policy map to a port:
1.
Click Traffic, DiffServ.
2.
Select Configure Interface from the Step list.
3.
Check the box under the Ingress field to enable a policy map for a port.
4.
Select a policy map from the scroll-down box.
5.
Click Apply.
Figure 139: Attaching a Policy Map to a Port
