C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 124 –
Show VLAN Statistics
Shows statistics for protocol messages and number of active
groups
Show Port Statistics
Shows statistics for protocol messages and number of active
groups
Show Trunk Statistics
Shows statistics for protocol messages and number of active
groups
Routing Protocol
RIP
Routing Information Protocol
General
Configure
Enables or disables RIP, sets the global RIP attributes and timer
values
Clear Route
Clears the specified route type or network interface from the
routing table
Network
Add
Sets the network interfaces that will use RIP
Show
Shows the network interfaces that will use RIP
Passive Interface
Add
Stops RIP broadcast and multicast messages from being sent on
specified network interfaces
Show
Shows the configured passive interfaces
Neighbor Address
Add
Configures the router to directly exchange routing information with
a static neighbor
Show
Shows adjacent hosts or interfaces configured as a neighboring
router
Redistribute
Add
Imports external routing information from other routing domains
(that is, protocols) into the autonomous system
Show
Shows the external routing information to be imported from other
routing domains
Distance
Add
Defines an administrative distance for external routes learned from
other routing protocols
Show
Shows the administrative distances assigned to external routes
learned from other routing protocols
Interface
Add
Configures RIP parameters for each interface, including send and
receive versions, authentication, and method of loopback
prevention
Show
Shows the RIP parameters set for each interface
Modify
Modifies RIP parameters for an interface
Statistics
Show Interface Information
Shows RIP settings, and statistics on RIP protocol messages
Show Peer Information
Displays information on neighboring RIP routers
Table 6: Switch Main Menu (Continued)
Menu
Description
Page
