Multi-Service IronWare Multiprotocol Label Switch (MPLS) Configuration Guide
815
53-1003031-02
Displaying 6PE information
9
BGP4 Summary
Router ID: 10.40.40.1 Local AS Number: 1
Confederation Identifier: not configured
Confederation Peers:
Maximum Number of IP ECMP Paths Supported for Load Sharing: 1
Number of Neighbors Configured: 1, UP: 1
Number of Routes Installed: 4, Uses 344 bytes
Number of Routes Advertising to All Neighbors: 2 (2 entries), Uses 96 bytes
Number of Attribute Entries Installed: 4, Uses 360 bytes
Neighbor Address AS# State Time Rt:Accepted Filtered Sent ToSend
10.30.30.1 1 ESTAB 0h35m18s 2 0 2 0
Syntax: show ip bgp 6pe summary
describes the output parameters of the show ip bgp 6pe summary command.
TABLE 159
Output parameters of the show ip bgp 6pe summary command
Field
Description
Router ID
Shows the neighbor router ID.
Local AS Number
Shows the value of the Local AS configured.
Confederation Identifier
Shows the AS number of the confederation in which the router resides.
Confederation Peers
Shows the numbers of the local Autonomous Systems contained in the confederation.
This list matches the confederation peer list the user configures on the router.
Maximum Number of IP
ECMP Paths Supported
for Load Sharing
Shows the maximum number of route paths across which the router can balance
traffic to the same destination.
Number of Neighbors
Configured
Shows the number of BGP4 neighbors configured on this router, and currently in the
ESTABLISHED state.
Number of Routes
Installed
Shows the number of BGP4 routes in the BGP4 route table and the route or path
memory usage.
Number of Routes
Advertising to All
Neighbors
Shows the total of the RtSent and RtToSend columns for all neighbors and the amount
of memory used by these groups.
Number of Attribute
Entries Installed
Shows the number of BGP4 route-attribute entries in the route-attributes table and the
amount of memory used by these entries.
Neighbor Address
Shows the IP addresses of the BGP4 neighbors for this router.
AS#
Shows the AS number.
