Brocade1# show mpls vpls name c1
VPLS c1, Id 10, Max mac entries: 8192
Total vlans: 0, Tagged ports: 0 (0 Up), Untagged ports 0 (0 Up)
Total VPLS peers: 1 (0 Operational)
auto-discovery enabled, RD 10:10
export RT 10:10
import RT 10:10
Peer address: 10.2.2.2 (auto-discovered), State: Wait for functional local ports
Tnnl in use: None
LDP session: Up, Local VC lbl: 983040, Remote VC lbl: N/A
Local VC MTU: 1500, Remote VC MTU: 0
CPU-Protection: OFF
Local Switching: Enabled
Brocade1# show mpls vpls name c2
VPLS c2, Id 20, Max mac entries: 8192
Total vlans: 0, Tagged ports: 0 (0 Up), Untagged ports 0 (0 Up)
Total VPLS peers: 1 (0 Operational)
auto-discovery enabled, RD 10:20
export RT 10:20
import RT 10:20
Peer address: 10.2.2.2 (auto-discovered), State: Wait for functional local ports
Tnnl in use: None
LDP session: Up, Local VC lbl: 983072, Remote VC lbl: N/A
Local VC MTU: 1500, Remote VC MTU: 0
CPU-Protection: OFF
Local Switching: Enabled
Multi-Service IronWare Multiprotocol Label Switch (MPLS) Configuration Guide 775
53-1003031-02
Displaying VPLS auto-discovery information
8
Displaying VPLS auto-discovery information
The user can display the following information about the VPLS auto-discovery configuration:
• L2VPN VPLS address family and associated routes
• VPLS auto-discovered peers
• Load balancing status for VPLS auto-discovered peers
• LDP configuration, including the loopback interface and router ID
Displaying information about BGP L2VPN VPLS routes
The user can use the show ip bgp l2vpn vpls command with the parameters listed in Table 145 to
view information related to BGP L2VPN VPLS routes.
TABLE 145 Parameters for CLI command show ip bgp l2vpn vpls
Parameter Displays... For details, see...
A.B.C.D or A.B.C.D/L
(route IP address) The BGP L2VPN VPLS routes for a particular IP route
address page 777
attribute-entries AS-path attribute entries page 778
neighbors Details about TCP and BGP neighbor connections page 780
rd Details about the route distinguisher page 785
routes Information about BGP L2VPN VPLS routes page 786
summary A summary of the BGP L2VPN VPLS neighbor status page 788
