TABLE 147 Output for the show ip bgp l2vpn vpls attribute-entries command
This field... Displays
Total number of BGP Attribute
Entries The number of routes contained in this device’s BGP L2VPN VPLS route
table.
Next Hop The IP address of the next hop router for routes that have this set of
attributes.
Metric The cost of the routes that have this set of attributes.
Origin The source of the route information. The origin can be one of the following:
•
EGP – The routes with this set of attributes came to BGP through EGP.
•
IGP – The routes with this set of attributes came to BGP through IGP.
•
INCOMPLETE – The routes came from an origin other than one of the
above. For example, they may have been redistributed from OSPF or
RIP.
NOTE: When BGP4 compares multiple routes to a destination to select the
best route, IGP is preferred over EGP and both are preferred over
INCOMPLETE.
Originator The originator of the route in a route reflector environment.
Cluster List The route-reflector clusters through which this set of attributes has passed.
Aggregator Aggregator information:
•
AS Number
shows the AS in which the network information in the
attribute set was aggregated. This value applies only to aggregated
routes and is otherwise 0.
•
Router-ID shows the router that originated this aggregator.
Atomic Indicates whether the network information in this set of attributes has been
aggregated and this aggregation has resulted in information loss.
NOTE: Information loss under these circumstances is a normal part of BGP4
and does not indicate an error.
Local Pref The degree of preference for routes that use this set of attributes relative to
other routes in the local AS.
Communities The communities to which routes with this set of attributes belong.
Extended Community The extended community attributes.
AS Path The AS path through which routes with this set of attributes have passed.
The local AS is shown in parentheses.
Address This field is an internal value used for debugging purposes only.
Links This field in an internal value used for debugging purposes only.
Reference Counts This field is an internal value used for debugging purposes only.
