Displaying BGP or MPLS VPNv4 information
6
Displaying summary route information
To display summary statistics for all the VPNv4 routes in the device’s BGP route table, enter a
command such as the following at any level of the CLI.
Brocade# show ip bgp vpnv4 routes summary
Total number of BGP routes (NLRIs) Installed : 184
Distinct BGP destination networks : 184
Filtered bgp routes for soft reconfig : 0
Routes originated by this router : 4
Routes selected as BEST routes : 184
BEST routes not installed in IP forwarding table : 0
Unreachable routes (no IGP route for NEXTHOP) : 0
IBGP routes selected as best routes : 90
EBGP routes selected as best routes : 90
Syntax: show ip bgp vpnv4 routes summary
This display shows the following information.
NLRIs Sent in Update Message The number of NLRIs for new routes the has sent to this neighbor in
UPDATE messages:
•
Withdraws – The number of routes the device has sent to the
neighbor to withdraw.
•
Replacements – The number of routes the device has sent to
the neighbor to replace routes the neighbor already has.
Peer Out of Memory Count for Statistics for the times the device has run out of BGP4 memory for
the neighbor during the current BGP4 session:
•
Receiving Update Messages – The number of times UPDATE
messages were discarded because there was no memory for
attribute entries.
•
Accepting Routes (NLRI) – The number of NLRIs discarded
because there was no memory for NLRI entries. This count is
not included in the Receiving Update Messages count.
•
Attributes – The number of times there was no memory for
BGP4 attribute entries.
•
Outbound Routes (RIB-out) – The number of times there was no
memory to place a “best” route into the neighbor's route
information base (Adj-RIB-Out) for routes to be advertised.
TABLE 118 BGP VPNv4 summary route information
This field... Displays...
Total number of BGP VPNv4 routes (NLRIs)
Installed The number of BGP VPNv4 routes the device has installed in the BGP
route table.
Distinct BGP VPNv4 destination networks The number of destination networks the installed routes represent.
The BGP route table can have multiple routes to the same network.
Filtered BGP VPNv4 routes for soft reconfig The number of route updates received from soft-reconfigured
neighbors or peer groups that have been filtered out but retained.
TABLE 117 BGP4 route summary information for a VPNv4 neighbor (Continued)
This field... Displays...
