524
Multi-Service IronWare Multiprotocol Label Switch (MPLS) Configuration Guide
53-1003031-02
Overview
4
NOTE
MPLS cannot be configured on the system globally when a NI-MLX-10Gx8-D card is installed.
This chapter explains how to configure MPLS Virtual Leased Line (VLL) on a Brocade device. Virtual
Leased Line is also known as Pseudo Wire Emulation as defined by the IETF PWE3 Working Group.
MPLS VLL is a method for providing point-to-point Ethernet or VLAN connectivity over an MPLS
domain. This functionality is outlined in the IETF documents
“draft-ietf-pwe3-control-protocol-14.txt” and “draft-ietf-pwe3-ethernet-encap-08.txt”.
This chapter is divided into the following sections:
•
525 describes how packets are encapsulated and forwarded
over an MPLS VLL.
•
“Example 2: CoS behavior for dual-tagged to single-tagged VLL endpoints”
describes how to set up MPLS VLLs on devices using the Command Line Interface (CLI).
•
“Displaying MPLS VLL information”
547 describes the commands used to display
information about an MPLS VLL configuration.
•
“Sample MPLS VLL configuration”
555 illustrates a sample MPLS VLL configuration
and lists the CLI commands used for implementing it.
Dual-tags for
VLL-local
Yes
Yes
No
No
No
No
No
MPLS
Signalling:
RSVP-TE
support
Yes
Yes
No
Yes
No
No
Yes
Traps for VLLs
Yes
Yes
No
Yes
No
No
Yes
MPLS Local
VLL Traps
Yes
Yes
No
Yes
No
No
Yes
Disabling
Syslog
Messages for
MPLS
VLL-Local and
VLL
Yes
Yes
No
Yes
No
No
Yes
Extended
Counters
support for VLL
and Local VLL
Yes
Yes
No
No
No
No
No
VLL Raw Pass
Through
Yes
Yes
No
Yes
No
No
Yes
TABLE 81
Supported Brocade MPLS Virtual Leased Line (VLL) features (Continued)
Features
supported
Brocade
NetIron XMR
Series
Brocade
MLX Series
Brocade
NetIron CES
2000 Series
BASE
package
Brocade
NetIron CES
2000 Series
ME_PREM
package
Brocade
NetIron CES
2000 Series
L3_PREM
package
Brocade
NetIron CER
2000 Series
Base
package
Brocade
NetIron CER
2000 Series
Advanced
Services
package
