Static transit LSP
1
VLL peers = 0
Peers operational = 0
Local VLLs:
VLLs configured = 0
VLLs operational = 0
CSPF-GROUP:
Total configured = 0
Tunnels:
Total supported = 16000
Total allocated = 2
Cross-connects:
Total supported = 64000
Total allocated = 1
Auto-bandwidth templates:
Total supported = 100
Total configured = 0
Number of times MPLS has been enabled: 1
TABLE 10 Field definitions
Field Definition
Transit-LSPs configured Number of static LSP transits configured
Transit-LSPs enabled Number of static LSP transits enabled
Transit-LSPs operational Number of static LSP transits operational.
Syntax: show mpls summary
Show mpls forwarding
The show mpls forwarding command display now includes static-configured LSPs in the Signaling
protocol part. “S “will be used to indicate static when no protocol is used.
Brocade# show mpls forwarding
R: RSVP L: LDP S: Static
Total number of MPLS forwarding entries: 3
Dest-prefix In-lbl Out-lbl Out-intf Sig Next-hop
1 44.44.44.44/32 - 3 e2/15 R 14.1.1.4
2 44.44.44.44/32 1024 3 e2/15 L 14.1.1.4
3 0.0.0.0/0 100 101 e3/14 S 12.1.1.2
4 0.0.0.0/0 101 102 e1/9 S 1.1.1.41
Syntax: show mpls forwarding
Show mpls config
The show mpls config command shows the configuration inside MPLS. The display now includes
the configuration of static transit LSPs.
Brocade# show mpls config
