Configuring the DH-485 Interface
57
4. Make entries in the following fields:
5. Select OK. The selected options are stored as part of the current GML
Commander diagram. The dialog box closes.
Field
Description
Baud Rate
Select the baud rate for your DH-485 network.
Important: Every item on the link must have
the same baud rate.
Node Address
Type the node address number (0 through 31)
for this controller.
Max Node
Address
Type the highest number of possible addresses
for devices on this network.
