Rockwell Automation GMLC Reference Manual User Manual
Page 868
Publication GMLC-5.2 - November 1999
Using the Online Toolbar
831
Clear All Breakpoints
Clears all breakpoints from the currently
selected diagram
Online Connection
Toggles the communication with the motion
controller on or off
Diagram Download
Translates and downloads the diagram to the
motion controller
Upload Options
Allows upload of program scripts, variables,
cam points, or all
Debug Mode
Toggles the debug mode to normal (English
text, diagram trace) or terminal (iCODE text,
trace)
Select direct command
Select a direct command from list of online
commands to execute
Execute Direct Command
Opens the dialog box for the direct command
in the list of direct commands
Re-execute Direct
Command
Executes the last executed direct command
again
Online button
Diagram menu
command
Description
